Lexium Cobot is a series of collaborative robots designed to assist workers with repetitive manual tasks. This cobot controller monitors collaborative robots with a payload of 3 kg and an input voltage of 100 V to 240 V AC, 50-60 Hz. It features a high-speed input for line tracking, 16 digital inputs/outputs, and two analog inputs/outputs. Lexium Cobot is designed to assist workers in completing repetitive and tedious tasks and protect their health through assembly line automation. It has an IP44 protection rating. It features a communication interface (RJ45 connector) for TCP/IP, Modbus TCP, Modbus RTU, ProfiNet, and Ethernet/IP. It is constructed of aluminum and steel and weighs 12 kg. It measures 410 mm wide, 307 mm high, and 235 mm deep. This cobot controller is designed to stand on the floor and be installed next to the robot arms in their workspace. It is certified according to GB11291.1, EN ISO10218-1, EN60204-1, EN ISO12100, EN ISO13849-1, EN61000-6-2, EN61000-6-4 +A1, ISO13849-1/2, ISO14644-1/9001, and CE marked. This cobot controller monitors collaborative robots with a 3 kg payload. It is connected to the robot via a 6-meter-long cable. It is designed to stand on the floor and be placed near the robot. Collaborative robots are work companions for humans and make their work easier. The collaborative robot is a step towards Industry 4.0, in which the operator will work together with intelligent and manipulative robots.
